This instruction manual provides detailed guidance for assembling and maintaining your Revell 07741 Tyrrel P34/2 6-Wheeler 1:32 Scale Plastic Model Kit. The Tyrrell P34-2 was a revolutionary Formula 1 racing car, notable for its unique six-wheel configuration, which debuted in 1977. This kit allows you to recreate this iconic vehicle with precision and detail, featuring a faithful replica of its innovative design, high-quality plastic parts, authentic cockpit equipment, and realistic decals.
The kit is designed for experienced model builders due to its complexity, rated at skill level 5 by Revell. Careful attention to the instructions and proper use of tools and materials are essential for a successful build.
Image: The packaging for the Revell Tyrrel P34/2 6-Wheeler 1:32 scale model kit, showing the completed model on a racetrack.
Inona no ao anaty boaty
Before beginning assembly, please verify that all components listed below are present in your kit. If any parts are missing or damaged, please contact Revell customer support.
- Complete plastic model kit parts (unbuilt, on sprues)
- Detailed, multilingual building instructions with step-by-step illustrations
- High-quality decal sheet for true-to-the-original design
Image: Various plastic sprues containing the unbuilt components of the Revell Tyrrel P34/2 model kit, including body panels, chassis, and wheels.
Torolàlana momba ny fivoriambe
This model kit requires assembly, painting, and decaling. Please read the entire instruction manual before starting. Recommended tools (not included) typically include plastic cement, hobby knife, side cutters, sandpaper, paint, and brushes.
- Fiomanana: Carefully remove all parts from the sprues using side cutters. Clean any excess plastic (flash) with a hobby knife or sandpaper.
- Sub-Assembly: Follow the illustrated instructions to assemble smaller components first, such as the engine, cockpit, and suspension.
- Hosodoko: Paint parts according to the color guide provided in the instructions. Allow paint to dry completely before proceeding.
- Fivoriambe lehibe: Attach sub-assemblies to the main chassis and body. Ensure proper alignment and secure bonding with plastic cement.
- Decals: Apply decals carefully using water and a decal setting solution for best results. Refer to the decal placement guide.
- Antsipirian-kevitra farany: Attach any remaining small parts, such as mirrors, antennas, and the rear wing.
Sary: akaiky view of the detailed cockpit interior of the assembled Tyrrel P34/2 model, showing the steering wheel and instrument panel.
Sary: A antsipirihany view of the engine assembly within the Tyrrel P34/2 model, highlighting the intricate components and exhaust system.
Image: The underside of the Tyrrel P34/2 model, showcasing the chassis, suspension, and the unique small front wheels.
Image: A close-up of the rear wing and associated aerodynamic elements on the Tyrrel P34/2 model, complete with "elf" and "GOOD YEAR" decals.
Display and Care
Once assembled, your Revell Tyrrel P34/2 model is a display piece. Handle it with care to prevent damage to delicate parts and paintwork.
- Toerana fampisehoana: Place your model on a stable, flat surface away from direct sunlight, extreme temperatures, and high humidity to prevent fading or warping.
- Fanadiovana: Dust regularly with a soft, dry brush or a gentle air blower. Avoid using harsh chemicals or abrasive cloths, which can damage the paint and decals.
- Fikarakarana: Always pick up the model by its sturdy base or main body. Avoid touching delicate parts like wings, mirrors, or antennas.
Famahana olana iraisana
Here are solutions to common problems encountered during model kit assembly:
| OLANA | vahaolana |
|---|---|
| Parts do not fit together properly. | Ensure all sprue gates are cleanly removed. Lightly sand mating surfaces if necessary. Verify part numbers against the instructions. |
| Decals do not adhere or wrinkle. | Ensure the surface is clean and glossy. Use decal setting solution to help decals conform to irregular surfaces and eliminate air bubbles. |
| Paint finish is uneven or rough. | Apply paint in thin, even coats. Ensure proper ventilation and temperature. Allow sufficient drying time between coats. Lightly sand between coats if needed. |
| Small parts break during removal or assembly. | Use sharp, appropriate tools (e.g., fine-point hobby knife, precision side cutters). Exercise caution and apply minimal force. Repair with plastic cement if possible. |
fepetra arahana
| endri-javatra | antsipirihany |
|---|---|
| Marika | Revell |
| Anarana modely | Revell 07741 Tyrrel P34/2 6-Wheeler 1:32 Scale Unbuilt/Unpainted Plastic Model Kit |
| Laharana modely | 07741 |
| ambaratonga | 1:32 |
| KEVITRA | plastika |
| Isan'ny Pieces | 105 |
| Ny refin'ny entana (L x W x H) | 5.31 x 2.48 x 1.34 santimetatra (13.5 cm x 6.3 cm x 3.4 cm) |
| Lanja entana | 8.1 ounces (0.23 kilao) |
| Taona soso-kevitra | Adult (Skill Level 5) |
| Anisan'ny singa | Model Kit, Decal Set, Product Manual |
| Languages (Manual) | Anglisy, Frantsay, Alemana, Italiana, Espaniola |
Warranty Information
Revell model kits are manufactured to high-quality standards. Specific warranty details for this product are typically included within the product packaging or can be found on the official Revell website. Azafady, tehirizo ny porofon'ny fividiananao raha misy fitakiana fiantohana.
Fanohanana ny mpanjifa
For technical assistance, missing parts, or general inquiries regarding your Revell model kit, please contact the manufacturer directly.
- Mpanamboatra: Carrera Revell Europe GmbH
- Webtranokala: Miangavy anao hitsidika ilay manam-pahefana Revell webtoerana raha mila fanazavana fanampiny momba ny fifandraisana sy ny loharano fanohanana.
