1. Fampidirana
Misaotra anao nividyasing the DANFI AUDIO DF TE-2017 Vinyl Record Player. This manual provides essential information for the safe and correct operation of your new record player. Please read it thoroughly before use and retain it for future reference.
2. Ny votoatin'ny fonosana
- DANFI AUDIO DF TE-2017 Vinyl Record Player
- 45 adaptatera RPM
- Power Cord & Adapter (100-240V~)
- Fanjaitra fanoloana
- Takelaka mihodina
- Torolàlana ho an'ny mpampiasa (ity antontan-taratasy ity)
3. Vokatra mihoatraview
The DANFI AUDIO DF TE-2017 is a versatile 3-speed belt-drive turntable with built-in speakers, Bluetooth wireless playback, USB/SD recording, AUX input, and RCA output. It features a clear dust cover and a digital display for easy operation.
Sary 1: Eo anoloana sy aoriana View of the TE-2017 Record Player with Labeled Components. This image displays the turntable platter, spindle, 45 RPM adapter, tone arm lift lever, speed selection switch, auto stop on/off switch, tone arm lock, stylus, speakers, AUX input, Mode/TF/USB controls, LED display, RCA audio out, and power port.
4. Fametrahana
- Famoahana: Esory tsara ao anaty fonosana ny mpitendry rakikira sy ny kojakoja rehetra. Tazomy ny fonosana mba ho azo ampiasaina amin'ny fitaterana na fitahirizana amin'ny ho avy.
- Fametrahana sarona vovoka: Slide the clear plastic dust cover into the brackets located at the rear of the turntable. Ensure it is securely seated.
- Fampifandraisana herinaratra: Connect the power adapter to the DC 5V/1A port on the rear of the record player and plug it into a wall outlet.
- Fametrahana: Place the record player on a stable, level surface away from direct sunlight, heat sources, and excessive dust or vibrations.
- Fiarovana Stylus: Remove the stylus protective cap before playing a record.
5. Torolàlana miasa
5.1 Fandefasana Rakitra Vinyl
- Herim-batana: Turn the ON/OFF/VOLUME knob clockwise to power on the unit and adjust the volume.
- Safidio ny fomba: Set the PH/BT/AUX/USB switch to 'PH' (Phono) mode.
- Firaketana toerana: Place a vinyl record on the turntable platter. If playing a 7-inch single, use the included 45 RPM adapter.
- Select Speed: Adjust the 3-speed selection switch (33, 45, 78 RPM) to match the record's speed.
- Auto-Stop (Optional): If desired, set the Auto Stop ON/OFF switch to 'ON'. The turntable will stop spinning automatically when the record finishes.
- Toerana misy ny sandry feo: Gently lift the tone arm using the lift lever. Move the tone arm over the desired track of the record.
- Sandry Feo Ambany: Slowly lower the tone arm onto the record using the lift lever. The music will begin to play.
- Adjust Pitch: Use the PITCH control knob to fine-tune the playback speed if necessary.
- Faranana ny famerenana: At the end of the record, lift the tone arm, return it to its rest, and lower the lift lever. Turn the ON/OFF/VOLUME knob counter-clockwise to power off.
Video 1: Demonstration of Vinyl Playback Mode on an LP&No.1 Turntable with Built-in Speakers. This video illustrates how to place a record, position the tone arm, and initiate playback, highlighting the smooth operation of the turntable.
5.2 Bluetooth Wireless Playback
- Herim-batana: Turn the ON/OFF/VOLUME knob clockwise to power on the unit.
- Safidio ny fomba: Set the PH/BT/AUX/USB switch to 'BT' (Bluetooth) mode. The digital display will show 'BT' and the indicator light will blink blue, indicating pairing mode.
- Fitaovana mampiaraka: On your smartphone, tablet, or other Bluetooth-enabled device, search for 'Turntable' in the Bluetooth settings and select it to pair. Once connected, the indicator light will stop blinking and remain solid blue.
- Milalao mozika: Start playing music on your paired device. The audio will stream through the record player's built-in speakers.
- Ahitsio Volume: Control the volume using the ON/OFF/VOLUME knob on the record player or your paired device.
Lahatsary 2: Mihoatraview of Record Player with Speakers, demonstrating Bluetooth connectivity. This video shows how to switch to Bluetooth mode, pair a mobile device, and stream audio wirelessly to the turntable's speakers.
5.3 USB/SD Recording and Playback
- Insert USB/SD: Insert a USB flash drive or SD card into the corresponding port on the front panel.
- Safidio ny fomba: Set the PH/BT/AUX/USB switch to 'USB' mode. The digital display will show 'USB'.
- Playback: The unit will automatically detect and play audio files from the USB/SD device. Use the control buttons (Previous Song, Pause & Play, Next Song) to navigate tracks.
- Recording Vinyl to USB/SD:
- Atombohy ny fandefasana rakikira vinyl araka ny voalaza ao amin'ny fizarana 5.1.
- Press the 'REC' button (if available, typically near the USB/SD slot) to begin recording. The indicator light may change to confirm recording is active.
- Press 'REC' again to stop recording. The recorded audio will be saved as an MP3 file on the USB/SD device.
- Use the 'SPLIT' button (if available) to create separate tracks during recording.
Video 3: USB Playback & Vinyl to MP3 Recording demonstration. This video shows how to insert a USB drive, initiate recording from vinyl, and manage recorded files, highlighting the digital conversion feature.
5.4 AUX Input
- Herim-batana: Turn the ON/OFF/VOLUME knob clockwise to power on the unit.
- Safidio ny fomba: Set the PH/BT/AUX/USB switch to 'AUX' mode.
- Mampifandray fitaovana: Connect an external audio device (e.g., MP3 player, CD player) to the AUX IN port on the rear of the record player using a 3.5mm audio cable (not included).
- Play Audio: Play audio from your external device. The sound will be output through the record player's speakers.
- Ahitsio Volume: Control the volume using the ON/OFF/VOLUME knob on the record player or the external device.
5.5 RCA Output
- Connect External Speakers: Connect external powered speakers or an amplifier to the RCA OUT ports (red for right, white for left) on the rear of the record player using an RCA cable (not included).
- Play Audio: Play a vinyl record or stream via Bluetooth/AUX. The audio will be routed through the connected external audio system.
- Ahitsio Volume: Control the volume primarily through your external audio system. The record player's volume knob may still affect the output level.
Sary 2: aoriana view of the TE-2017 Record Player, illustrating the RCA output ports connected to external speakers for enhanced audio quality.
5.6 Jack écouteur
For private listening, plug 3.5mm headphones into the headphone jack located on the front panel. The built-in speakers will be muted automatically.
6. Fikojakojana
- Fanadiovana ny Stylus: Use a soft brush (not included) to gently clean the stylus from back to front. Do not use excessive force.
- Fanadiovana ny mpilalao firaketana: Fafao amin'ny lamba malefaka sy maina ilay fitaovana. Aza mampiasa mpanadio abrasive na solvents.
- Sarona vovoka: Keep the dust cover closed when not in use to protect the turntable from dust and debris.
- Fikarakarana Rakitra: Handle records by their edges. Store them vertically in their sleeves to prevent warping and dust accumulation.
7. Famahana olana
| OLANA | Antony mety hitranga | vahaolana |
|---|---|---|
| Tsy misy hery | Adapter herinaratra tsy mifandray na fivoahana diso. | Hamarino tsara fa mifandray tsara ny adaptatera herinaratra ary miasa tsara ny fantson-jiro. |
| Tsy misy feo avy amin'ny mpandahateny | Ambany loatra ny feo; diso ny fomba voafantina; mifandray ny écouteur. | Increase volume; select correct mode (PH, BT, AUX, USB); disconnect headphones. |
| Turntable tsy mihodina | Power off; belt dislodged; auto-stop engaged prematurely. | Ensure power is on; check belt (refer to maintenance); try disabling auto-stop. |
| Mandalo na mivadika feo | Kapila maloto na simba; stylus maloto na tonta; tsy mitovy lenta ny takelaka mihodina. | Diovy ny rakikira; diovy na soloy ny stylus; ataovy izay hahazoana antoka fa mitovy tsara ny turntable. |
| Bluetooth tsy mampiaraka | Incorrect mode; device too far; device already paired. | Ensure 'BT' mode is selected; move device closer; unpair from other devices. |
8. Famaritana
- marika: DANFI AUDIO DF
- Modely: TE-2017
- Hafainganam-pandeha miolikolika: 33 1/3, 45, 78 RPM
- Karazana fiara: Belt Drive
- Fifandraisana: Bluetooth Receiver, USB, SD Card, AUX Input, RCA Output
- Endri-javatra manokana: Digital Recorder, WAV Converter, Digital Display, Pitch Control, Auto-Stop
- Loharano herinaratra: Tariby elektrika misy tariby (DC 5V/1A)
- Signal-to-noise ratio (dB): 78 dB
- Haben'ny vokatra: 35.56 x 27.94 x 12.45 sm (14 x 11 x 4.9 santimetatra)
- Lanja: 3.07 kg (6.77 lbs)
9. Warranty sy fanohanana
For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official DANFI AUDIO DF website. Tehirizo ny porofon'ny fividiananao raha misy fitakiana fiantohana.
