1. Fampidirana
This manual provides essential information for the safe and efficient operation, assembly, and maintenance of your ESKUTE Polluno Plus 26" Electric Bicycle. Please read this manual thoroughly before your first ride and keep it for future reference. Understanding the instructions will ensure optimal performance and longevity of your e-bike.
2. Information momba ny fiarovana
Your safety is paramount. Always wear a helmet and appropriate safety gear when riding. Adhere to all local traffic laws and regulations. Regular maintenance checks are crucial for safe operation.
Torolàlana momba ny fiarovana ankapobe:
- Fanamarinana mialohan'ny fiara: Before each ride, inspect brakes, tires, battery charge, and all quick-release mechanisms.
- Fepetra mitaingina: Avoid riding in adverse weather conditions, on slippery surfaces, or at night without proper lighting.
- Fetran-danja: Aza mihoatra ny tanjaka ambony indrindra 125 kg (275 lbs).
- Fikarakarana bateria: Only use the provided charger. Do not expose the battery to extreme temperatures or puncture it.
- Ankizy: This e-bike is intended for adults. Keep children away from moving parts and charging components.
3. Inona no ao anaty boaty
Rehefa avy mamaha ny fonosana dia ataovy izay hahazoana antoka fa eo daholo ireto singa manaraka ireto:
- 1 x ESKUTE Polluno Plus E-bike
- 1 x 36V 20Ah Lithium-ion Battery
- 1 x Battery Charger
- 1 x Fitaovana Fitaovana Fivoriambe
- 1 x Boky Torolàlana
Sary: Overview of the ESKUTE Polluno Plus Electric Bicycle and its main components.
4. Fametrahana sy Fivoriambe
Follow these steps to assemble your ESKUTE Polluno Plus electric bicycle.
4.1. Fanokafana ny boaty sy fiomanana voalohany
- Position the box vertically and carefully cut the plastic straps and metallic clips.
- With assistance, lift the e-bike out of the box and place it on its kickstand.
- Remove all protective packaging (bubble wrap) from the frame, handlebars, and seat. Use hands, a knife, or scissors carefully to avoid damaging components.
4.2. Handlebar and Stem Adjustment
- Release the quick-release lever on the handlebar stem.
- Lift the handlebar into its vertical riding position.
- Adjust the handlebar height to your preference and securely close the quick-release lever.
- Esory ny clamp on the handlebar itself, rotate the handlebar to a comfortable position, and re-tighten the clamp.
Image: The LCD display and handlebar controls of the ESKUTE Polluno Plus. The display shows battery level and assistance mode.
4.3. Fanitsiana ny seza
- Open the quick-release mechanism located on the seat post clamp.
- Amboary ny haavon'ny seza mba hahazoana toerana mahafinaritra rehefa mitaingina, ary ataovy izay hahafahan'ny tongotrao mikasika ny tany rehefa mijanona.
- Securely close the quick-release mechanism to fix the seat in place.
4.4. Fametrahana Pedal
- Identify the left (L) and right (R) pedals. The right pedal screws in clockwise, and the left pedal screws in counter-clockwise.
- Insert the right pedal into the right crank arm and tighten it using a 15mm wrench.
- Repeat the process for the left pedal. Ensure both pedals are securely tightened.
5. Torolàlana miasa
Learn how to operate your ESKUTE Polluno Plus electric bicycle effectively.
5.1. Battery Usage and Charging
The ESKUTE Polluno Plus features a removable 36V 20Ah battery. It can be charged both on and off the bike.
- To Remove Battery: Use the key to unlock the battery from the frame. Carefully slide the battery out.
- To Insert Battery: Slide the battery back into the frame until it clicks into place. Lock it with the key.
- famandrihana: Connect the charger to the battery's charging port, then plug the charger into a power outlet. The indicator light on the charger will show charging status.
Image: A hand inserting the removable 36V 20Ah battery into the frame of the ESKUTE Polluno Plus electric bicycle.
5.2. Powering On/Off and Display
To power on the e-bike, press and hold the power button on the LCD display. The display will show battery level, speed, and assistance mode. To power off, press and hold the power button again.
5.3. Assistance Levels and Gear Shifting
The ESKUTE Polluno Plus features a 250W brushless motor and a 7-speed Shimano gear system. Use the '+' and '-' buttons on the display to adjust the pedal assistance level. Shift gears using the Shimano shifter on the handlebar to match terrain and desired effort.
Image: Diagram illustrating the powerful 250W motor and intelligent torque sensor, which provides smooth and responsive pedal assistance.
5.4. rafitra frein
The e-bike is equipped with 160mm mechanical disc brakes for reliable stopping power. Always apply both brakes simultaneously for controlled deceleration. Familiarize yourself with the brake levers before riding at speed.
5.5. Folding Mechanism (if applicable)
While the ESKUTE Polluno Plus is not a folding e-bike, some models may have folding handlebars or pedals. If your model includes these features, refer to the specific instructions for folding and unfolding to ensure secure locking mechanisms.
6. Fikojakojana
Regular maintenance ensures the longevity and safe operation of your ESKUTE Polluno Plus e-bike.
- Fanerena kodiarana: Check tire pressure before each ride. Maintain recommended PSI levels for optimal performance and safety.
- Famenoana rojo: Lubricate the chain regularly, especially after riding in wet conditions, to prevent rust and ensure smooth gear changes.
- Fanaraha-maso ny frein: Periodically check brake pads for wear and brake cables for tension. Adjust or replace as needed.
- Fanadiovana: Clean your e-bike with a damp lamba sy savony malefaka. Fadio ny fanasana amin'ny tsindry ambony mivantana amin'ny singa elektrika.
- Fasteners: Ensure all bolts, nuts, and quick-release levers are securely tightened.
Image: The 60mm front suspension fork of the ESKUTE Polluno Plus, designed to absorb shocks and improve ride comfort on various terrains.
7. Famahana olana
This section addresses common issues you might encounter with your ESKUTE Polluno Plus e-bike.
| OLANA | Antony mety hitranga | vahaolana |
|---|---|---|
| Tsy mandeha ny bisikileta elektrika | Batterie tsy voaloa na tsy nampidirina tsara. | Ensure battery is fully charged and securely locked in place. Check battery power button is ON. |
| Tsy manome fanampiana ny motera | Low battery, assistance level set to zero, or sensor issue. | Charge battery, increase assistance level on display. Check for any loose cable connections. |
| Mahatsiaro ho malemy ny frein | Worn brake pads, loose cables, or disc contamination. | Inspect and replace brake pads if worn. Adjust cable tension. Clean brake discs with appropriate cleaner. |
| Feo tsy mahazatra mandritra ny dia an-tongotra | Loose components, dry chain, or misaligned gears. | Check all fasteners. Lubricate chain. Inspect gear alignment and adjust if necessary. |
8. Famaritana
Detailed technical specifications for the ESKUTE Polluno Plus 26" Electric Bicycle.
- Laharana modely: ES-26T
- Haben'ny kodia: 26 santimetatra
- Motor: 250W Brushless Motor
- Batterie: 36V 20Ah Lithium-ion (720Wh)
- Maherin'ny: Up to 120 KM (74 Miles) in assisted mode
- Hafainganam-pandeha ambony indrindra: 25 km/ora (15.5 mph)
- Gears: Shimano 7-hafainganam-pandeha
- frein: 160mm Mechanical Disc Brakes
- Fitaovana Frame: 6061 Aluminum Alloy
- Fiatoana eo anoloana: 60mm Travel with Lockout
- Lanja: 26.3 kg (58 lbs)
- Fahafahana enta-mavesatra: 125 kg (275 lbs)
- Haavo mpitaingina soso-kevitra: 165 - 190 cm (5'5" - 6'3")
- Toetoetra: LCD Display, LED Front Light, Multifunctional Rear Rack, Torque Sensor
Image: The ESKUTE Polluno Plus electric bicycle, highlighting its aluminum alloy frame, adjustable components, and key specifications like weight and load capacity.
9. Warranty sy fanohanana
For warranty information, please refer to the documentation included with your purchase or visit the official ESKUTE website. If you encounter any issues not covered in this manual, or require technical assistance, please contact ESKUTE customer support. Keep your proof of purchase for warranty claims.
