OKVEQUIP 13.5HP Mini Crawler Hydraulic Excavator (Model GT10Hcab) User Manual

1. Fampidirana

This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your OKVEQUIP 13.5HP Mini Crawler Hydraulic Excavator, Model GT10Hcab. Please read this manual thoroughly before operating the machine to ensure proper usage and to prevent injury or damage.

2. Information momba ny fiarovana

FAMPITANDREMANA: Ny tsy fanarahana ireo toromarika fiarovana ireo dia mety hiteraka ratra mafy na fahafatesana.

• Always wear appropriate personal protective equipment (PPE), including hard hat, safety glasses, gloves, and steel-toed boots.
• Ataovy azo antoka fa tsy misy olona eo akaikin'ny toeram-piasana, indrindra fa ny ankizy sy ny biby fiompy.
• Inspect the excavator before each use for any damage, leaks, or loose parts.
• Never operate the machine under the influence of alcohol or drugs.
• Be aware of your surroundings, including overhead power lines, underground utilities, and unstable ground.
• Always lower the bucket and engage the parking brake before leaving the operator's seat.
• Refer to local regulations and safety standards for operating heavy machinery.

3. Vokatra mihoatraview ary Features

The OKVEQUIP GT10Hcab is a compact 1-ton hydraulic excavator designed for various construction, garden, and farm tasks. It features a robust design with an enclosed cab for operator comfort and protection.

Lafin-javatra fototra:

• Famolavolana lalamby: Equipped with engineering rubber tracks featuring a deep texture design and dual-row anti-slip for stable grip on various terrains, including mud. Tracks are wear-resistant and include built-in steel plates for stable driving.
• Front Bulldozer Shovel: Made of alloy manganese steel, this hydraulically driven shovel can be adjusted up and down for backfilling and leveling operations, providing auxiliary support during excavation.
• High-Quality Oil Cylinder: Forged oil cylinders ensure good sealing and prevent oil leaks. The hydraulic transmission provides stable performance, and thickened protective plates extend service life. Independent oil pipelines contribute to a sturdy structure and smooth operation.
• Durable Enclosed Cab: The driver's cabin features high-transparency glass for safety and visibility. Comfortable, shock-absorbing seats are ergonomically designed to reduce operator fatigue during extended work periods.
• Multi-Purpose Bucket: The thickened excavator bucket offers large capacity and durability. It can be used in conjunction with the mechanical thumb clip to enhance work efficiency.
• RATO Engine: Powered by a RATO engine, ensuring low energy consumption, low noise, fuel efficiency, and stable performance.

Figure 1: OKVEQUIP GT10Hcab Mini Excavator with Cab, showing overall dimensions.

Sary 2: View of the enclosed cab, designed for operator comfort and protection in various weather conditions.

Figure 3: The powerful RATO engine, providing reliable performance for demanding tasks.

Figure 4: The adjustable front bulldozer shovel, useful for leveling and backfilling.

Figure 5: Standard configuration showing the excavator bucket and mechanical thumb clip for enhanced versatility.

4. Fametrahana

Upon delivery, the excavator is typically packaged in a wooden crate to ensure protection during transit. Careful handling is required during unpacking.

Famoahana sy fisavana voalohany:

1. Ensure you have appropriate lifting equipment, such as a forklift, to safely unload the crated excavator.
2. Carefully remove the wooden casing. Inspect the machine for any visible damage that may have occurred during shipping.
3. Check all fluid levels (engine oil, hydraulic fluid, coolant) and top up if necessary according to the specifications.
4. Familiarize yourself with the location of all controls and safety features before starting the engine.

Figure 6: The excavator is shipped in a wooden case, requiring a forklift for safe unloading.

5. Torolàlana miasa

Operating the OKVEQUIP GT10Hcab requires understanding its controls and functions. Always ensure you are in a safe operating environment and have completed all pre-operation checks.

Fampandehanana fototra:

1. Manomboka ny motera: Follow the manufacturer's instructions for starting the RATO engine. Ensure all safety levers are in the neutral or locked position.
2. Control Levers: The excavator is controlled via hydraulic levers located inside the cab. These levers control the movement of the boom, arm, bucket, and swing functions.
3. mitondra fiara: Use the foot pedals or hand levers (depending on configuration) to control the track movement. The bulldozer blade can be raised or lowered using its dedicated control.
4. fihadiana: Practice smooth and controlled movements. Avoid sudden jerks. Digging depth and dumping height can be precisely controlled.
5. Mikatona: Park the excavator on level ground, lower the bucket and bulldozer blade to the ground, engage the parking brake, and turn off the engine.

6. Fikojakojana

Regular maintenance is crucial for the longevity and optimal performance of your OKVEQUIP GT10Hcab excavator. Adhere to the maintenance schedule outlined below.

Fanamarinana fikojakojana mahazatra:

• isan'andro: Check engine oil level, hydraulic fluid level, coolant level, fuel level, and inspect tracks for damage or excessive wear. Clean the air filter if necessary.
• isan-kerinandro: Lubricate all grease points. Check battery terminals for corrosion. Inspect all hoses and connections for leaks.
• Monthly/50 Hours: Change engine oil and oil filter. Inspect and adjust track tension. Check all bolts and nuts for tightness.
• Annually/250 Hours: Replace hydraulic fluid and filter. Inspect hydraulic cylinders for leaks or damage. Check and adjust valve clearances (refer to engine manual).

Always use genuine OKVEQUIP replacement parts and recommended lubricants. Consult a qualified technician for complex repairs or if you are unsure about any maintenance procedure.

7. Famahana olana

This section provides solutions to common issues you might encounter with your excavator. For problems not listed here, or if solutions do not resolve the issue, contact customer support.

8. Famaritana

Detailed technical specifications for the OKVEQUIP GT10Hcab Mini Crawler Hydraulic Excavator.

9. Warranty sy fanohanana

OKVEQUIP provides customer support for its products. For any inquiries regarding your GT10Hcab excavator, including operational assistance, parts, or warranty claims, please contact the seller or OKVEQUIP customer service.

The product typically includes a 30-day easy return policy. For specific warranty details, refer to the documentation provided at the time of purchase or contact customer support.
