Actualia FLYWING Bell-206-V2 RC Helicopter User Manual

Sava lalana

This manual provides essential instructions for the safe operation, setup, and maintenance of your Actualia FLYWING Bell-206-V2 RC Helicopter. Please read this manual thoroughly before operating the helicopter to ensure proper function and to prevent damage or injury.

Torolàlana manan-danja momba ny fiarovana

• Operate the helicopter in open areas, away from people, animals, and obstacles.
• Always maintain a safe distance from the rotating blades.
• Aza miasa amin'ny rivotra mahery na ny toetr'andro ratsy.
• Ensure all parts are securely fastened before each flight.
• Keep hands and face clear of the helicopter during operation.
• Ny fanaraha-maso olon-dehibe dia atolotra ho an'ny mpampiasa latsaky ny 14 taona.
• Do not attempt to modify the helicopter or its components.
• Use only approved charging equipment and batteries.

Fonosana fonosana

Rehefa voasokatra ny fonosana dia hamarino tsara fa eo daholo ny entana rehetra ary ao anatin'ny toe-javatra tsara:

• Assembled Fuselage (1)
• Handcrafted Painted Integrated Shell (1)
• Handcrafted Painted Head Cover (1)
• Batterie (1)
• Digital Display Charger (1)
• Remote Control Transmitter (1)
• Spare Main Rotor Blades (1 pair)
• Spare Tail Rotor Blades (1 pair)
• Screwdriver and small parts (for maintenance)
• User Manual (ity antontan-taratasy ity)

Image: The Bell-206-V2 helicopter, remote control, battery, and charger as included in the RTF package.

Famantarana singa

Helicopter Overview

Sary: lafiny anoloana view of the Bell-206-V2 RC Helicopter.

The Bell-206-V2 RC Helicopter features a realistic scale design. Key components include:

• Main Rotor Blades: Provide lift and control.
• Tail Rotor: Controls yaw (left/right rotation) and counteracts main rotor torque.
• Fiara fiara: The main body, housing electronics and battery.
• Landing Skids: Support the helicopter during takeoff and landing.
• Efitra bateria: Located on the underside of the fuselage.
• H1 Flight Controller: Integrated system for stable flight and advanced features.
• Motera tsy misy borosy: Provide efficient and powerful propulsion for main and tail rotors.

Transmitter Remote Control

Image: The remote control transmitter with various sticks and buttons.

Ny fitaovana fanaraha-maso lavitra:

• Left Stick (Throttle/Yaw): Controls altitude and left/right rotation.
• Right Stick (Pitch/Roll): Mifehy ny hetsika mandroso/mihemotra sy havia/ havanana.
• Hery Switch: Mandefa ny lavitra / miala.
• Bokotra fanapahana: Ho an'ny fanitsiana tsara ny fitoniana amin'ny sidina.
• One-Key Takeoff/Landing Button: Initiates or concludes flight automatically.
• Fiovan'ny sidina: Selects between different flight modes (e.g., GPS Stabilized, 3D Manual).
• Return-to-Home Button: Activates the automatic return function.

Torolàlana fametrahana

1. Famandrihana ny bateria angidimby

1. Connect the provided digital display charger to a power source.
2. Connect the helicopter battery to the charger.
3. Monitor the digital display for charging status. The battery is fully charged when the indicator shows completion.
4. Disconnect the battery once fully charged. Do not overcharge.

2. Fametrahana Batterie amin'ny Remote Control

1. Sokafy ny efitranon'ny bateria ao ambadiky ny fanaraha-maso lavitra.
2. Insert the required batteries (typically AA, not included) according to the polarity markings.
3. Akatona tsara ny efitranon'ny bateria.

3. Installing the Helicopter Battery

1. Locate the battery compartment on the underside of the helicopter.
2. Carefully insert the charged battery into the compartment, ensuring a snug fit.
3. Connect the battery cable to the helicopter's power port.
4. Secure the battery compartment cover if applicable.

4. Propeller Check

Before the first flight, and periodically thereafter, ensure the main and tail rotor blades are securely attached and free from damage. If any blades are damaged, replace them with the provided spares using the screwdriver.

Torolàlana miasa

1. Power On and Binding

1. Apetraho amin'ny toerana fisaka sy mitovy lenta ny angidimby.
2. Turn on the helicopter's power switch. The indicator lights will flash.
3. Turn on the remote control. The remote will automatically bind with the helicopter. A solid light on both devices indicates successful binding.

2. Fanaraha-maso ny sidina fototra

• One-Key Takeoff: Press the dedicated "Takeoff" button on the remote. The helicopter will automatically ascend to a stable hovering altitude.
• Throttle (Left Stick Up/Down): Increases or decreases altitude.
• Yaw (Tehina havia havia/havanana): Rotates the helicopter left or right on its vertical axis.
• Pitch (Right Stick Up/Down): Moves the helicopter forward or backward.
• Roll (Right Stick Left/Right): Moves the helicopter sideways (strafe) left or right.
• Fipetrahana tokana: Press the dedicated "Landing" button. The helicopter will automatically descend and land.

3. Advanced Flight Modes and Features

• GPS Stabilized Mode: Provides automatic and precise hovering, ideal for beginners.
• 3D Manual Mode: Offers high-speed responsiveness for aerobatic maneuvers like flips, rolls, and inverted flight.
• Famerenana tokana tokana: Activates automatic return to the takeoff point.
• Low Battery Return: Helicopter automatically returns to the takeoff point when battery is low.
• Loss of Control Return: Helicopter automatically returns if signal is lost.
• One-Key Inverted Flight: Allows for quick inversion for advanced maneuvers.
• Semi-Autonomous Assisted Flight: Supports pre-determined flight paths such as circular motion and figure-8 routes.

4. Flight Tips

• Start with GPS Stabilized Mode for learning.
• Practice hovering and gentle movements before attempting advanced maneuvers.
• Always keep the helicopter within visual range.
• Monitor battery levels to ensure safe return.

Image: The Bell-206-V2 RC Helicopter flying outdoors.

fikarakarana

• Fanadiovana: Use a soft, dry cloth to clean the helicopter after each flight. Avoid water or harsh chemicals.
• Blade Inspection: Regularly check main and tail rotor blades for cracks, bends, or damage. Replace damaged blades immediately.
• Henjana visy: Periodically inspect all screws, especially those on the main rotor clamp axle and tail rotor, and tighten if necessary.
• fitahirizana: Store the helicopter and remote control in a cool, dry place, away from direct sunlight and extreme temperatures. Remove batteries from the remote for long-term storage.

Fanamboarana

fepetra arahana

Warranty sy fanohanana

Raha mila fanazavana momba ny garantie, fanohanana ara-teknika, na kojakoja fanolo, dia jereo azafady ny adiresy ofisialin'ny mpanamboatra. webtranokala na mifandray amin'ny departemantan'ny serivisy mpanjifany. Tehirizo ny tapakila fividiananao ho porofon'ny fividianana.
