LOYALHEARTDY 43cc 2-Stroke Gasoline Pole Chainsaw User Manual

Sava lalana

This manual provides essential information for the safe and effective operation, assembly, and maintenance of your LOYALHEARTDY 43cc 2-Stroke Gasoline Pole Chainsaw. Please read this manual thoroughly before initial use and keep it for future reference. Proper understanding and adherence to these instructions will ensure optimal performance and user safety.

Sary: The LOYALHEARTDY 43cc Pole Chainsaw, fully assembled, showcasing ny endriny sy ny singany.

Sary: The pole chainsaw positioned with contextual images of trees, highlighting its intended use for various tree trimming tasks.

Information momba ny fiarovana

FAMPITANDREMANA: Ny tsy fanarahana ireo toromarika fiarovana ireo dia mety hiteraka ratra mafy na fahafatesana.

Fitsipika fiarovana ankapobeny

• Manaova fitaovana fiarovana manokana (PPE) sahaza foana, anisan'izany ny solomaso fiarovana, ny fiarovana ny sofina, ny fonon-tanana ary ny kiraro mafy.
• Do not operate the pole saw when fatigued, under the influence of alcohol, drugs, or medication.
• Keep children, bystanders, and pets at a safe distance (at least 15 meters / 50 feet) from the work area.
• Inspect the pole saw before each use for loose parts, damage, or fuel leaks. Do not operate a damaged tool.
• Ensure the work area is clear of obstacles, power lines, and other hazards.
• Never operate the pole saw in poor lighting conditions or adverse weather.
• Always hold the pole saw firmly with both hands during operation.
• Be aware of kickback. Avoid cutting with the tip of the guide bar.
• Never modify the pole saw. Use only manufacturer-approved replacement parts and accessories.

Fiarovana ny solika

• Mix gasoline and 2-stroke oil in a well-ventilated area, away from sparks or open flames.
• Use a mixing ratio of 20-25:1 (Gasoline:Oil).
• Store fuel in an approved container, away from heat sources.
• Aza mameno solika mihitsy raha mafana ny motera. Avela hangatsiaka ny motera vao asiana solika.
• Fafao avy hatrany izay solika raraka.

Fiarovana ny fanapahana

• Plan your cuts. Identify the fall direction of the branch.
• Maintain a balanced stance and secure footing.
• Fadio ny manapaka mihoatra ny haavon'ny soroka.
• Be aware of falling branches and debris.
• Never stand directly under the branch being cut.

Fonosana fonosana

Esory tsara ny singa rehetra ary jereo amin'ny lisitra etsy ambany. Raha misy singa tsy hita na simba dia mifandraisa amin'ny serivisy ho an'ny mpanjifa.

Sary: All components included with the LOYALHEARTDY 43cc Pole Chainsaw. This includes the engine unit, two extension pole segments, the chainsaw cutting head, a saw chain, a guide bar, a guide bar cover, a fuel mixing bottle, a small tool kit, safety goggles, and a shoulder strap.

• 43cc 2-Stroke Engine Unit
• Chainsaw Cutting Head with 12-inch Guide Bar
• Saw Chain (3/8" pitch)
• Extension Pole Segments (1.09m / 3.58ft) - Quantity: 2
• Main Pole Shaft
• Shoulder Harness/Strap
• Tavoahangy fangaro solika
• Kitapo fitaovana (Lakile, Visy, sns.)
• Solomaso fiarovana
• Cover Bar Guide
• Anglisy User Manual

Torolàlana momba ny fivoriambe

Follow these steps to assemble your pole chainsaw. Ensure all connections are secure before operation.

1. Attach the Chainsaw Head: Align the chainsaw cutting head with the end of the main pole shaft. Secure it firmly using the provided coupling mechanism and tighten any fasteners.
2. Install the Guide Bar and Chain:
   • Remove the chain cover from the chainsaw head.
   • Carefully place the saw chain around the sprocket and guide bar. Ensure the cutting edges of the chain are facing the correct direction.
   • Mount the guide bar onto the studs on the chainsaw head.
   • Replace the chain cover and loosely install the nuts.
   • Adjust the chain tension using the tensioning screw until the chain is snug but can still be pulled freely around the guide bar by hand.
   • Henjano tsara ireo voanjo amin'ny fonon'ny rojo.


   Sary: antsipiriany view of the chainsaw head, guide bar, and chain assembly, illustrating proper installation.

3. Connect Extension Pole Segments (Optional): If additional reach is required, connect the extension pole segments between the main pole shaft and the engine unit. Ensure all connections are fully engaged and secured. The total length can reach up to 3.5 meters (11.5 feet) with the extension pole segments.


Sary: Assembled pole chainsaw illustrating its adjustable length, ranging from 240cm to 350cm (approximately 7.87 to 11.48 feet) with the extension pole segments.

4. Attach the Handle and Shoulder Harness: Install the ergonomic front handle onto the main pole shaft at a comfortable position. Attach the shoulder harness to the designated points on the pole saw to distribute weight and reduce fatigue during operation.
5. Connect the Engine Unit: Securely attach the engine unit to the other end of the main pole shaft (or extension pole if used). Ensure all electrical and mechanical connections are properly made.

Hametraka

Fampifangaroana solika

Your pole saw is powered by a 2-stroke gasoline engine and requires a specific fuel mixture. Use fresh, unleaded gasoline with an octane rating of 89 or higher, mixed with high-quality 2-stroke engine oil.

• Fampifangaroana tahan'ny: 20-25 parts gasoline to 1 part 2-stroke oil (20:1 to 25:1).
• Use the provided fuel mixing bottle for accurate measurement.
• Pour the required amount of 2-stroke oil into the mixing bottle first, then add gasoline up to the marked level for your desired ratio.
• Shake the mixture thoroughly before pouring it into the pole saw's fuel tank.
• Fahavitan'ny tanky solika: 1000ml (33.81 oz).

Sary: antsipiriany view of the engine unit, highlighting the fuel tank and related components for fuel filling.

Chain Lubrication

The chainsaw chain requires continuous lubrication during operation. Fill the chain oil reservoir with good quality bar and chain oil. Do not use waste oil or motor oil, as this can damage the chain and guide bar.

• Locate the chain oil reservoir cap on the chainsaw head.
• Fill the reservoir with bar and chain oil.
• Ensure the cap is securely tightened after filling.

Torolàlana miasa

Manomboka ny motera

1. Apetraho eo amin'ny toerana fisaka sy mafy orina ny tsofa hazo.
2. Ensure the chain brake is engaged (if applicable).
3. Set the choke lever to the "FULL CHOKE" position.
4. Tsindrio imbetsaka ny takamoa primer mandra-pahitana ny solika eo amin'ny tsipika fiverenana.
5. Pull the starter cord firmly and smoothly until the engine attempts to start (usually 1-3 pulls).
6. Once the engine "pops" or attempts to start, move the choke lever to the "HALF CHOKE" or "RUN" position.
7. Pull the starter cord again until the engine starts.
8. Avela hafana kely ny motera alohan'ny hanindriana ny "throttle".
9. If the engine does not start after several pulls, refer to the Troubleshooting section.

Teknika manapaka

Sary: User demonstrating the LOYALHEARTDY pole chainsaw in action, reaching a high tree branch for trimming.

Always maintain a firm grip on the pole saw with both hands. Use the shoulder harness to support the weight and maintain balance.

• Pre-cutting Inspection: Before each cut, assess the branch for tension, potential kickback, and clear a safe fall path.
• Undercutting: For larger branches, make a small undercut on the underside of the branch first. This prevents the branch from splitting and pinching the guide bar.
• Top Cut: Make the main cut from the top of the branch, slightly further out from the undercut.
• Final Cut: After the main weight of the branch has fallen, make a final clean cut closer to the main trunk or limb, ensuring not to cut into the branch collar.
• Avoir overreaching: Do not extend the pole saw beyond a comfortable and stable reach.
• Hafaingan'ny rojo: Always operate the saw at full throttle when cutting to ensure proper chain speed and lubrication.

fikarakarana

Regular maintenance ensures the longevity and safe operation of your pole saw.

Aorian'ny fampiasana tsirairay

• Diovy ny Unit: Remove sawdust, debris, and sap from the guide bar, chain, and engine cooling fins.
• Jereo ny fihenjanana amin'ny rojo vy: Ensure the chain tension is correct. Adjust if necessary.
• Check Chain Lubrication: Verify the chain oil reservoir is adequately filled.
• Jereo raha misy fahasimbana: Look for any loose fasteners, damaged parts, or fuel leaks.

Fikojakojana ara-potoana

• Fanatsarana rojo: A dull chain requires more effort to cut and can cause kickback. Sharpen the chain regularly or replace it when necessary. Refer to a professional if unsure.
• Fikojakojana ny Bar Guide: Clean the guide bar groove and oil holes. Flip the guide bar periodically to ensure even wear.
• Fanadiovana sivana rivotra: Clean or replace the air filter as needed to maintain engine performance.
• Fanaraha-maso ny fanilo: Inspect and clean the spark plug. Replace if worn or fouled.
• Sivana solika: Inspect and replace the fuel filter if it appears clogged.

Fanamboarana

fepetra arahana

Warranty sy fanohanana

For warranty information or technical support, please refer to the documentation included with your purchase or contact LOYALHEARTDY customer service. Keep your purchase receipt as proof of purchase.

Mpanamboatra: FAWEIUS

Laharana modely: G97RG943HFUOE

Daty misy voalohany: 11 aogositra 2022
