JESLED LED Strip 10M SMD 5050 RGB Lights

1. Ny votoatin'ny fonosana

Azafady mba hamarino tsara fa ao anaty fonosanao avokoa ireo singa rehetra:

• 10M (2x 5M) JESLED SMD 5050 RGB LED Strip
• Controller Bluetooth
• 44-Key IR Remote Control
• Adapter herinaratra (24V)
• Connectors and Adhesive Clips

Sary 1: Vitaview of the JESLED LED Strip package contents, showing the LED strips, remote, power adapter, and various accessories.

2. Torolàlana fananganana

2.1 Fanomanana

• Unspool the Strips: Before powering on, completely unspool the LED strips from their reels. Operating the strips while still spooled can cause overheating and damage.
• Madio Surface: Ataovy azo antoka fa madio, maina ary malama ny velaran'ny fametrahana mba hahazoana ny fiasan'ny lakaoly tsara indrindra.

Image 2: Visual guide for installation, illustrating the importance of unspooling LED strips to prevent overheating and showing the designated cut marks for customization.

2.2 Torolàlana momba ny fifandraisana

1. Connect LED Strip to Controller: Align the arrow on the LED strip connector with the arrow on the Bluetooth controller's output cable. Insert firmly.
2. Connect Power Adapter to Controller: Plug the power adapter's DC output into the input port of the Bluetooth controller.
3. Esory ny takelaka bateria lavitra: If applicable, pull out the clear plastic tab from the 44-key remote control to activate its battery.
4. Ampidiro amin'ny Outlet Power: Connect the power adapter to a suitable electrical outlet.

Image 3: Step-by-step connection diagram for the LED strip, controller, and power adapter, highlighting the arrow alignment for proper connection.

2.3 Customization (Cutting)

The LED strips are cuttable at designated marks. Look for the copper pads with a scissor icon. Cut only at these marks. Cutting elsewhere will damage the strip. Connectors are included for rejoining cut sections if needed.

3. Torolàlana miasa

3.1 Using the 44-Key Remote Control

The remote control allows for basic and advanced functions:

• ON/OFF: Ampireheto na vonoy ny jiro.
• Safidy loko: Choose from 20 preset static colors.
• Fanitsiana famirapiratana: Ampitomboy na ahenao ny hamafin'ny hazavana.
• DIY Buttons (DIY1-DIY6): Customize and save your preferred colors. Press a DIY button, then use the RGB arrows to adjust the color, and press the DIY button again to save.
• Safidy fomba: Access various dynamic modes like Flash, Strobe, Fade, and Smooth.
• Fanitsiana haingam-pandeha: Control the speed of dynamic modes.

Image 4: Illustration of the 44-key remote control, detailing its buttons for power, color selection, brightness, DIY color customization, and various lighting modes.

3.2 Mampiasa ny Bluetooth App

For enhanced control and features, download the dedicated Bluetooth app:

1. Misintona fampiharana: Scan the QR code in the product packaging or search for the app name (usually 'HappyLighting' or similar, check packaging for exact name) in your device's app store.
2. Alefaso ny Bluetooth: Alefaso ny Bluetooth amin'ny finday na takelakao.
3. mampifandray: Open the app. It should automatically detect and connect to your LED strip controller.
4. Endri-javatra mifehy: The app offers a color wheel for precise color selection, various dynamic modes, music synchronization, microphone mode, and a timer function.

Image 5: The smartphone app interface for controlling the LED strips, featuring a color wheel for custom colors and icons for various functions like music sync and timing.

3.3 Music Synchronization Mode

The LED strip can synchronize its lighting effects with music or ambient sound:

• App Music Mode: Within the app, select the 'Music' tab to play music from your device, and the lights will react to the rhythm.
• Fomba mikrô: Use the 'Mic' tab in the app, or select the music mode on the remote, to allow the built-in microphone on the controller to pick up ambient sounds and music, making the lights dance to the beat.

Image 6: Depiction of the LED strip's music synchronization feature, showing lights changing in response to sound, creating an immersive atmosphere.

4. Fikojakojana

4.1 Fanadiovana

To clean the LED strips, gently wipe them with a dry, soft cloth. Do not use liquid cleaners or abrasive materials, as these can damage the strip or its components. Ensure the power is disconnected before cleaning.

4.2 Fitehirizana

If storing the LED strips for an extended period, ensure they are clean and dry. Roll them loosely back onto their original reels or a similar spool to prevent kinking or damage to the circuit board.

5. Famahana olana

• Jiro tsy mirehitra:
  - Check all connections (power adapter, controller, LED strip) to ensure they are secure and correctly aligned (arrow to arrow).
  - Verify the power adapter is plugged into a working outlet.
  - Ensure the plastic tab has been removed from the remote control battery compartment.
  - Try using the app to turn on the lights, or vice versa, to isolate the issue.
• Fanaraha-maso lavitra tsy mandeha:
  - Ensure the plastic battery tab is removed.
  - Replace the CR2025 battery in the remote if it's depleted.
  - Point the remote directly at the IR receiver on the controller.
  - Note: Some users report interference if multiple similar LED strips are in close proximity.
• App tsy mifandray:
  - Ensure Bluetooth is enabled on your device.
  - Restart the app and try again.
  - Restart your phone/tablet.
  - Unplug and replug the LED strip power to reset the controller.
  - Ensure no other device is currently connected to the LED strip via Bluetooth.
• Lights Changing Color Randomly:
  - This can sometimes occur due to interference from other IR devices or nearby LED strips. Try repositioning the controller or reducing other IR signals in the area.
  - Ensure the remote is not accidentally being pressed.
• Adhesive tsy mihazona:
  - Ensure the installation surface is clean, dry, and smooth before application.
  - Apply firm pressure along the strip during installation.
  - For rough or textured surfaces, consider using additional adhesive clips (included) or stronger mounting tape.
• Loko tsy mety aseho:
  - Check the arrow-to-arrow connection between the strip and controller. An incorrect connection can lead to color issues.
  - Try resetting the controller by unplugging and replugging the power.

6. Famaritana ara-teknika

7. Warranty sy fanohanana

7.1 Fampahalalana momba ny fiantohana

JESLED products typically come with a standard manufacturer's warranty. Please refer to the product packaging or the official JESLED website for specific warranty terms and conditions. Retain your proof of purchase for warranty claims.

7.2 Fanohanana ny mpanjifa

For technical assistance, troubleshooting, or warranty inquiries, please contact JESLED customer support through the retailer where the product was purchased or visit the official JESLED brand store:

JESLED Official Store on Amazon
